This manual armature winding machine is especially designed for winding even slot armatures. It`s suitable for hook or riser type commutator armature. This armature winding machine is widely used in many armatures field like automobile motor, motorcycle motor, house appliances series excited motor, power tool motor and various kinds of PM DC micro motor. It`s an economic, fast and reliable specialized winding machine.
(1) Main technical data:
Power suply Voltage: 220V±10%, 50HZ
Pre-set turns: 0-9999
Advance Turns: 0-9
Principal Axis Center Height: 170mm
Wire Diameter: 0.08-1.08mm
It is suitable for home appliance, car and power tool motor aramture.
Semi automatic Manual armature winding machine video
About Motor armature manufacturing
Motor armature / rotor manufacturing production assembly lineincluding:shaft pressing machine, end cover pressing machine, commutator pressing machine, armature insulation paper inserting machine, armature winding machine, commutator hot stacking machine, armature wedge inserting machine and armature testing machine, ball bearing inserting machine, and worm shaft inserting, NIDE can supply and manufacture about then ,and all the process will be done by machine automatically. Operator only needs to do loading and unloading.
Nide is to provide different kinds of motor manufacturing machinery, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.We can supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover,etc.We also providetechnical support and consulting, project support and turn-key service for some motor manufacturing.
Our machine's application
Our machines are mainly applied to induction motors, BLDC motor, universal motor, three phase motor, single phase motor, AC motor, DC motor, such as washing machine motor, air conditioner motor, pump motor, cooler motor, alternator motor, fan motor, ceiling fan motor, compressor motor, power tool motor, vacuum cleaner motor, mixer motor, series motor, electrical car motor, wheel hub motor, electric toothbrush motor, hair dryer motor, electric shaver motor,etc.
